Mdf / Pvc / Arylic / Pcb CNC Router Machine Fast Working Speed Frame Structure

Name: Mdf Pvc Arylic Pcb CNC Router Machine Fast Working Speed Frame Structure
Brand: BLUE ELEPHANT
Price: 1 USD

Best Mdf / Pvc / Arylic / Pcb CNC Router Machine Fast Working Speed Frame Structure wholesale

Brand Name : BLUE ELEPHANT

Model Number : ELE1325

Certification : CE, ISO9001，SGS，CIQ

Place of Origin : Jinan City, Shandong Province, China

MOQ : 1 set

Price : US $3,599 - 6,999 / Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 Set/Sets per

Delivery Time : 10-15 working days

Packaging Details : Standard marine export plywood case

Voltage : 380V, 3PH, 50/60HZ (optional: 220V)

Dimension(L*W*H) : 3200*2140*1850mm

Inverter : 5.5kw Taiwan Delta Inverter

Spindle power : 4.5kw

Spindle : Italy HSD air cooling Spindle

Spindle speed : 0-18000RPM

Motor : FL118 stepper motor

Driver : YAKO2608 Big Driver or Leadshine 860H driver

Control system : DSP Control System

Contact Now

4x8ft Chinese cheap cnc router , cnc mould die engraving machine , cnc machine 1325 for wood pcb mdf pvc arylic

Features of cnc router 1325:

working area -1300*2500*200mm
4.5kw Italy HSD air cooling spindle
Adopt FL118 stepper motor and YAKO 2608 big driver (or Leadshine 860H driver)
5.5kw Taiwan DELTA inverter
T-slot & vacuum table, with very powerful absorbing power, can absorb materials of different sizes.
DSP control system
With fast working speed, high working efficiency, the engraving speed can be up to 14m/min. The engraving is precise enough, without any Sawtooth ripple, and the cutting edge is quite clear and smooth.

Parameters of cnc router 1325:

Descriptions	Parameters
Modle	1325
Working area	13002500200mm
Control system	DSP control system
Spindle	4.5kw Italy HSD air cooling spindle
Motor	FL118 stepper motor
Driver	YAKO 2608 driver or Leadshine 860H driver
Inverter	5.5kw Taiwan DELTA inverter
X,Y transmission	X,Y axis helical rack and pinion drive
Z transmission	Z axis Taiwan TBI ball screw
Max Travelling speed	40000mm/min
Max Working speed	25000mm/min
Table Surface	Vacuum and T-slot working table
Structure	Frame structure

PS:All the working area and specifications can be customized according to your requests.

Machine details
Mdf / Pvc / Arylic / Pcb CNC Router Machine Fast Working Speed Frame Structure

Application

Furniture industry: folding screen, wave board, big wall hanging, advertising sheet, sign making.
Crafts industry: can be used for most materials like Artificial stone, wood, bamboo, marble, Organic board, Color plates, to do engraving of beautiful patterns and characters.
wood, acrylic, PVC, PCB, foam, aluminum, copper and so on.

Our service:

1, Within 7 days since your local customs clearance: if the cnc router’s any parts has any problems, we will change it free.

2, Exceed 7 days since your local customs clearance but within warranty period: if the cnc router parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.
3, Exceed warranty period: if the cnc router parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.
4, We offer 24 hours technical support by call, and email.
5, Our technician can give you remote guide online(Skype or MSN) if you have any question.
6, We can record videos of operating the laser machine.
7, Free training course in our factory.
8.Machine will be adjusted before it is delivered , operation disk/CD was included.
